Rebar Tensile Testing Machine with Video Extensometer
Test material: deformed steel bar, plain bar, steel bar, atbp.
Kapasidad ng pag load: 100kN, 200kN, 300kN, 600kN, 1000kN, 2000kN
Pamantayan sa pagsusulit: ISO6892, ASTM A615, BS4449, ISO15630, JIS3141, atbp.
Video extensometer: gauge length like 50mm, 100mm, 150mm, 200mm, atbp.
- Paglalarawan
- Pagtatanong
Paglalarawan
100kN Rebar Tensile Testing Machine with Video Extensometer
(side-action hydraulic operated tensile grip, high test efficiency, large gauge length video extensometer)
Panimula:
WDW-100L Computerized Electromechanical Universal Testing Machine is newly designed UTM with side-acting hydraulic operated tensile grip. Advanced side action hydraulic tensile grips provide high gripping performance for high strength and high hardness materials without any initial gripping force. Equipped with video extensometer, large gauge length, it is an ideal tensile testing machine for deformed steel bar, plain bar’s tensile and elongation test. The testing efficiency is much higher than the common type clip on extensometer. The test result is reliable.
It also can be used for tensile, compression, bending, etc test of other materials’ test, like steel, aluminum, copper, plastic, rubber, wood, alloy, PVC, spring, electrical wire and cable, composite, profiled bar, waterproof roll, atbp. They are essential testing instruments for quality testing section, university and college, research institution and industrial and mining enterprise. The machine is calibrated as ASTM E4, ISO 75001 international standard.
Pangunahing Teknikal na Mga Pagtutukoy:
| Model | WDW-100L |
| Host Machine Structure | double space, floor-standing type |
| Max Load Capacity (kN) | 100 |
| Class of Machine | 0.5 |
| Load Range | 0.4%-100% FS |
| Load Accuracy | Within ±0.5% of indicating load |
| Load Resolution | 1/500000 |
| Range of Deformation | 4%-100%FS |
| Resolution of Deformation (mm) | 0.001 |
| Accuracy of Displacement | Within ±0.5% of indicating value |
| Resolution of Displacement (mm) | 0.01 |
| Range of Testing Speed (mm / min) | 0.01 – 500 |
| Max Tensile Space(mm) | 600 |
| Max. Compression Space (mm) | 500 |
| Space Between Columns (mm) | 550 |
| Working environment | Room temperature 10℃~30℃, relative humidity≤80% |
| Power Supply | 3-Phase, 380V±10%, 50Hz, 3kW |
| Dimension of Host Machine (L×W×H, mm) | 1120×710×2210 |
| Net Timbang(KG) | 1200 |
