Máy chiếu để kiểm tra tác động charpy

Sự miêu tả

CST-50 Charpy Impact Projector

(Check the processing quality of V-notch and U-notch)

1. Ứng dụng & Đặc trưng:

It is designed according to the request of impact sample gap in GB/T229－2007 “Metal Charpy Impact Test Method”. It is an important special testing instrument to test if the impact sample gap is eligible. According to optical projection principle, the machine compare the impact sample U type gap or V type gap to standard map and judge if the sample is eligible. The operation is simple, direct, high efficient. So it is necessary testing instrument to machining the impact sample.

2. Thông số kỹ thuật chính:

Độ phóng đại：50×

Projector screen size：Ф200mm

Table displacement：vertical ±10mm，horizontal ±10mm，

up and down ±12mm

Rotate range of table：0～360°

Light：halogen and tungsten 12V, 100W

3. Check V-notch or U-notch quality
